Thermoelement-Kompensationskabel / -adern (IEC) Typ U (CCA) (SCA) PVC-isoliertes Flachpaar zur Verwendung mit Thermoelementen vom Typ R & S
Währung ändern
SKU
XE-2500
6,40 €
5,33 €
Leistungsbeschreibung
| Allgemeine Beschreibung | Good general purpose insulation for 'light' environments. Waterproof and very flexible. |
|---|---|
| Kabellänge | 10, 25, 50, 100m |
| Kabelart | Flat pair construction |
| Kern / Stränge | 7/0.2mm or 13/0.2mm |
| Leiterquerschnitt 7 / 0,2 (mm2) | 0.219 |
| Leiterquerschnitt 13 / 0,2 (mm2) | 0.408 |
| Außenfarbe | Orange |
| + Farbe | Orange |
| - Farbe | White |
| Dämm Material | PVC Insulated |
| Schleifenwiderstand 7 / 0,2 (Ohm pro kombiniertem Meter) | 0.2 |
| Loop Resistance 13/0.2 (Ohms per combined metre) | 0.1 |
| Max. Temperatur | +105°C |
| Mindest. Temperatur | -10°C |
| + Dirigentin | Copper |
| - Dirigentin | Copper Nickel |
| Bildschirm | No |
| Normen erfüllt | Colour code (cores & jacket) to IEC-584-3 |
| Thermoelementtyp | U (RCA) (SCA) |
| Toleranz | Class 2 |
Cable Reeling Video
Thermocouple Cables & Wire from Labfacility manufactured in the UK and distributed around the world. Available in 100m, 50m, 25m and 10m options. All Thermocouple Cables are held in stock ready to go.
